Locking Blocks Mold Parts

(Total 4 Products)

Customized Locating Components Block

Get Latest Price

Brand:yushun
Transportation:Ocean
Place of Origin:dongguan

Molds Parts description locating block components is an essential part of the manufacturing process. The mold block (also known as the tooling) is designed to create a specific shape or design, and the components are placed within the mold cavities...

Contact Now
custom steel metal stamping die parts

Get Latest Price

Brand:yushun
Transportation:Ocean
Place of Origin:dongguan

Locking Blocks Mold Parts description Stamping die parts are components used in the construction of stamping dies, which are specialized tools used to shape and form metal into desired shapes. Stamping die parts can include a wide range of...

Contact Now
Custom Locating Components Injection Mold Locking Block

Get Latest Price

Brand:yushun
Transportation:Ocean
Place of Origin:dongguan

A mold locking block is a component used in injection molding machines to keep the mold closed during the injection process. It is typically made of steel or other durable materials and is designed to withstand the high pressure and stress of the...

Contact Now
Mold Parts Locking Blocks with Angular Hole Process

Get Latest Price

Brand:yushun
Transportation:Ocean
Place of Origin:dongguan

Mold parts locking blocks are components of a mold used in injection molding processes. They are typically made of steel and are designed to hold the two halves of a mold together during the injection molding process. The locking blocks are usually...

Contact Now

Locking Blocks Mold Parts

Here are some common locking block mold parts:

Locking Blocks: These are typically metal or plastic blocks designed to fit together and secure the two halves of the mold. They provide stability and prevent any movement during the molding process.

Guide Pins: Guide pins are cylindrical rods that aid in aligning the two halves of the mold. They are usually inserted into holes on one half of the mold and fit into corresponding holes on the other half, ensuring precise alignment.

Guide Bushings: Guide bushings are hollow cylindrical components that help guide the guide pins. They are often made of hardened steel or other wear-resistant materials to withstand repeated use.

Locating Rings: Locating rings are circular discs with precision dimensions. They are installed on one side of the mold and act as reference points for aligning the two halves. They ensure accurate and consistent positioning of the mold during assembly.

Retaining Rings: Retaining rings are used to secure various components, such as guide pins and guide bushings, in place. They snap into grooves or slots on the mold parts, providing a secure hold.

Ejector Pins: Ejector pins are used to push the finished product out of the mold cavity once the molding process is complete. They are usually located on one half of the mold and extend into the mold cavity.

Slide Locks: Slide locks are mechanisms used in molds with sliding components or inserts. They enable the precise movement and locking of these elements, allowing for complex part designs.
